JK BAZ Line Filters are engineered to provide clean, contaminant-free compressed air by efficiently removing dust particles, oil aerosols, water droplets, and impurities from compressed air systems. Clean compressed air is essential for protecting pneumatic equipment, improving production quality, and reducing maintenance costs.
Our filters feature a robust aluminum housing, high-performance filter elements, and a low-pressure-drop design to ensure maximum system efficiency and long service life. Available in multiple filtration grades and capacities, JK BAZ Line Filters are suitable for all types of industrial compressed air installations.
Model Specifications
| Model | Flow Capacity | Connection Size | Max Pressure |
|---|---|---|---|
| JLF-015 | Up to 15 CFM | 1/4″ BSP | 16 Bar |
| JLF-030 | Up to 30 CFM | 3/8″ BSP | 16 Bar |
| JLF-060 | Up to 60 CFM | 1/2″ BSP | 16 Bar |
| JLF-120 | Up to 120 CFM | 3/4″ BSP | 16 Bar |
| JLF-250 | Up to 250 CFM | 1″ BSP | 16 Bar |
| JLF-500 | Up to 500 CFM | 2″ BSP | 16 Bar |
| JLF-1000 | Up to 1000 CFM | 3″ BSP | 16 Bar |
Filter Grades Available
| Grade | Removes |
|---|---|
| Pre Filter | Large dust particles and water droplets |
| Coalescing Filter | Fine oil mist and micron-sized particles |
| Fine Filter | Ultra-fine contaminants |
| Activated Carbon Filter | Oil vapour, odour, and hydrocarbons |
